Handling — Bin Tipper
Bin Tippers & Bin Lift Devices
Ergonomic bin emptying for 120–1100L bins. Nine models covering manual, electric and battery configurations — for standalone use or direct integration with compactors.
Overview
Ergonomic bin handling for any waste management workflow
Downwaste bin tippers are designed for ergonomic bin handling, providing efficient and seamless bin emptying for a variety of waste management equipment. Compatible with both standard and custom-made waste bins, these bin-lift devices integrate effortlessly with mobile or static compactors — or function as standalone units connected to existing waste handling systems.
For enhanced usability, our bin emptying systems offer an optional mechanical lid opener, ideal for large waste bins with round lids. Nine models span the full range of bin sizes and power requirements.
Models
Nine models — BT.001 to BT.010
From manual 240L tippers to high-lift battery models for 1100L bins — a configuration for every application and power environment.
BT.001
Mobile Manual — 240L (Chain Drive)
Manual chain-drive bin tipper for 240L bins. No power supply required. Compact and manoeuvrable for tight areas.
BT.002
Mobile Manual — 240L (Gas Spring)
Gas-spring-assisted manual tipper for 240L bins. Smooth, assisted lifting reduces operator effort.
BT.003
Mobile Manual — 240L (Hydraulic)
Hydraulic piston manual tipper for 240L bins. Consistent controlled lift with minimal operator force required.
BT.004
Mobile Electric — 120/240/360L (Cabled)
Electric bin tipper with cable power for 120, 240 and 360L bins. Suitable for fixed or semi-fixed positions within a facility.
BT.005
Mobile Electric — 120/240/360L (Battery)
Battery-powered tipper for 120, 240 and 360L bins. Fully mobile — no trailing cables. Ideal for large sites and multi-area operation.
BT.006
Mobile Electric — 660/770/1100L, 500kg (Cabled)
Heavy-duty electric tipper for large 660–1100L bins with 500kg load capacity. Cable powered for continuous high-volume operation.
BT.007
Mobile Electric — 660/770/1100L, 500kg (Battery)
Battery-powered version of the heavy-duty tipper for 660–1100L bins. Offers full site mobility with 500kg capacity.
BT.009
Mobile — 1100L & Bulky Material (Cabled)
Electric tipper for 1100L bins and bulky material containers. High-reach tip height for direct discharge into compactor hoppers.
BT.010
High-Lift — 1100L & Bulk (Battery)
High-lift battery tipper for 1100L and bulk containers. Extended lift height for connection to compactors and container inlets at height.
Features
Why specify a Downwaste bin tipper?
Ergonomic bin handling
Designed to eliminate manual lifting and tipping of heavy bins — protecting staff from musculoskeletal injuries and meeting manual handling regulations.
Wide bin compatibility
Compatible with standard 120, 240, 360, 660, 770 and 1100L bins as well as custom-made containers. Adaptors are available for non-standard configurations.
Compactor integration
Integrates directly with Downwaste mobile and static compactors, or connects to existing waste handling systems. Optional lid-opener for bins with round lids.
Manual, electric and battery options
Nine models spanning manual chain, gas spring, hydraulic piston, electric cabled and battery-powered variants — a solution for every site layout and power availability.
Optional mechanical lid opener
An optional mechanical lid opener is available for large waste bins with round lids, enabling hands-free bin loading and maintaining hygiene during emptying.
Standalone or integrated use
Functions as a standalone bin emptying unit connected to existing systems, or as a dedicated infeed device for Downwaste compactors — flexible to your workflow.
FAQ
Common questions
What is a bin tipper?
A bin tipper (also called a bin lifter) is a mechanical device that lifts and tips waste bins automatically, emptying the contents into a compactor, skip or collection point. It removes the need for manual tipping of heavy bins, protecting staff from injury and improving waste throughput.
Which bin sizes are compatible with Downwaste bin tippers?
Downwaste bin tippers cover 120L, 240L, 360L, 660L, 770L and 1100L standard bins. The BT.009 and BT.010 models also handle bulky material containers. Custom adaptors are available for non-standard bins.
What power options are available?
Models are available in three power configurations: manual (chain drive, gas spring or hydraulic piston), electric with cable, and battery-powered. Battery models provide full site mobility with no trailing cables.
Can bin tippers connect directly to a compactor?
Yes. Downwaste bin tippers are designed to integrate with mobile and static compactors — including Downwaste's own auger, static and press compactor range. The tipper lifts and tips the bin directly into the compactor hopper inlet.
What is the maximum load capacity?
The BT.006 and BT.007 models are rated to 500kg for 660–1100L bins. For lighter 120–360L bins, capacities vary by model — contact our UK team for specific weight ratings.
Is a lid-opener available?
Yes. An optional mechanical lid opener is available for bins with round lids. This allows hands-free loading of the bin before tipping, maintaining hygiene and reducing direct contact with waste.
How do I choose between cabled and battery models?
Cabled (electric) models are ideal where the tipper operates in a fixed or semi-fixed location with access to a 240V supply. Battery models suit mobile operations across large sites, multi-floor buildings or where trailing cables create a hazard.
Get a quote
Specify a bin tipper for your site
Tell us your bin sizes, volumes and site layout — our UK team will recommend the right model. Add to your quote or use the estimator for a guide price.
